Concrete Environmental Issues & The Ideal Concrete Plant





By: Doug Ruhlin

Envision a concrete plant - the most environmentally perfect concrete plant in the world. What's it like?

  • The plant is located near the customer base it serves, minimizing the transport of the finished product - concrete - to their customers, as well as the associated fuel use, traffic, and exhaust emissions. It's also located near public transportation, which many of the plant employees use.
  • The plant is also not far from their raw material sources. Cement kilns produce cement not too far away and sand and stone are produced nearby. Having several sources available, the concrete plant has selected their suppliers not only on the basis of quality and cost, but also since they share the same environmental vision as does the concrete plant and their parent company.
  • The plant makes use of supplemental cementiceous materials (SCMs) as much as possible in place of ordinary portland cement, thereby both reducing the greenhouse gas emissions and carbon footprint associated with cement, and also helping reduce the amount of waste the plant's area has to deal with. These materials include fly ash and slag, both of which also help to produce a superior product - no quality reductions at this plant.
  • The generation of process water is kept to as little as possible - and all process water generated is recycled for further concrete production. There is no discharge of any process water from this plant at all.
  • In order to reduce potable water use at the plant, stormwater capturing is used to collect this free source of clean water, which is then used for concrete production, truck washing, dust control, and green space watering. Some stormwater does runoff from the plant site, but under the control of appropriate stormwater BMPs and a SWPPP stormwater plan, which ensure that the stormwater leaving the site has little impact on adjacent waterways.
  • Due to careful sales and ordering practices, little returned concrete is generated. A strong QC program also ensure that few loads are rejected. What returned concrete there is goes to a concrete reclaimer which extracts the sand and stone in the concrete, and allows the process water and cement past to be recycled as part of new concrete production. There are no solid wastes generated at all.
  • Plant siting and construction was done with the environment in mind. Green areas remain, providing some wildlife habitat, a buffer of thick screening vegetation was preserved along property lines reducing noise and visual impact, and as much pervious concrete on the plant site as possible was used.
  • The plant's company regularly incorporates environmental training, and involves all employees in the plant's environmental program. All participate. The plant also regularly perform environmental audits to determine their compliance level.
  • In order to manage their environmental program, this concrete plant uses an environmental management system , and as result this plant has received the NRMCA Green-Star and/or ISO 14001 EMS certifications.
  • The plant uses jobsite rinseoff techniques for all loads delivered, and doesn't waste time or resources rinsing at the site. These include chute washoff buckets on most of the trucks.
  • And best of all, customers of this plant enjoy this difference, as do employees, neighbors, and corporate stockholders. They realize that this plant is a partner in their environmental vision, and they are willing to pay a premium for this difference. This plant also does a great job at telling people about their environmental achievements and vision. And, that's right, they get more for their concrete over the competition, and have a healthier bottom line.

Does this plant exist? Does this plant sound like yours, or is the other end of the spectrum from your plant?

I've yet to see this plant. But I have been fortunate enough to see plants which incorporate many of these traits, although maybe not all of them. How about your plant? How many of these traits do you employ? All of them? Some of them? Or, none of them?

Using this listing as a scorecard, where do you rank?

If you aren't the ideal concrete plant, don't worry - you're not alone. But you need to know that the industry is heading in this direction. Maybe not towards perfection (although that would be nice!), but towards continuous improvement. Getting better all the time. Reducing environmental impact. Becoming more sustainable.

Where do you stand? Where can you improve? What are you waiting for?



Contact Resource Management Associates



Comments

You have set a high standard here. Thats a good thing.



Titan has been having all kinds of trouble in the Wilmington NC trying to build a new plant. Hope they have a chance to see and absorb this post.



One question. The biggest resistance from the community has been the impact of emisions on air quality and the plant location on the coastal environment. You covered siting. How about emissions? Where and how does this bar get set?
Posted @ Friday, January 27, 2012 8:15 AM by Jonathan Ware
Jonathan - Thanks for the kind words, and I agree about the high standard. Gives one something to aim for!

Should anyone be having problems putting up a new plant, I may be able to be of help. I've done it several times, nearly all successfully.

Air issues are a public perception thing usually. It goes with what they think are the real impacts of a concrete plant, not what actually happens. Siting a plant can make a difference - generally speaking reduce wind and you reduce dust, so retention of trees, use of windbreaks, use of berms or depressional areas, agg bin containment, etc., all can help. But then, most in public view air issues as coming from the plant (process emissions) - which should be almost zero if plant is operating correctly, has adequate dust control technology on it, maintenance, etc. Really shouldn't be an issue. Fugitive dust is more of the issue, since it's not "equipment controlled" but BMP controlled, which can tail off when busy, etc. But with proper techniques, fugitives can also be easily controlled. So, in reality, air issues should not be the major concern. Now to convince the public of that...

Things like air modeling help, but it can be complicated and hard to grasp for the layman. They kind of think it's computer mumbo-jumbo from a paid consultant. But it's good stuff, and can be highly accurate.

Thanks again Jonathan - keep reading!

Doug Ruhlin
Posted @ Tuesday, January 31, 2012 5:00 PM by Doug Ruhlin
Doug, Great post.

Jonathan mentions that Titan is having a problem with a plant, is that a cement plant or concrete plant? just curious...
Posted @ Monday, February 20, 2012 7:23 AM by Owen Blevins
Titan is a cement plant. Would interesting to see an article on the "Ideal Cement Plant".
Posted @ Monday, February 20, 2012 8:07 AM by Jonathan Ware
