What a New Jersey SPCC Facility Diagram Has to Show, and How to Build One From Aerial Imagery or Site Plans

The facility diagram is one page, sometimes two, but it carries a lot of weight in an SPCC Plan. It shows a reviewer whether the person who wrote the Plan understood the site, and it's one of the places where we most often find deficiencies: missing containers, wrong capacities, piping that never shows up, or an unlabeled screenshot from a mapping website. For New Jersey facilities, where storm drains and streams are rarely far from the tank yard, a weak diagram also hides the question everyone cares about, which is how oil would reach the water.

This article walks through what the diagram has to show under the federal rule, how to handle containers, transfer areas, piping, secondary containment, drainage, and nearby waters, and how to build the drawing from aerial imagery or site plans. We've included an example diagram for a fictional New Jersey site so you can see how the pieces fit together. If you'd rather hand the whole thing off, you can reach out to RMA and we'll talk it through with you.

Table of Contents

TL;DR

An SPCC facility diagram is a site drawing in your Plan that marks the location and contents of every fixed oil container, the storage areas for mobile and portable containers, and all transfer stations and connecting pipes, with exempt underground tanks labeled as exempt. A diagram that also shows capacities, secondary containment, storm drains, flow direction, and nearby waters is much easier to defend and much more useful in a spill. Build it from a current aerial image or site plan plus a walk of the site, and update it whenever containers or piping change.

What Is an SPCC Facility Diagram and What Does the Rule Require?

The SPCC rule requires every Plan to describe the physical layout of the facility and include a facility diagram. The language sits in 40 CFR 112.7(a)(3). The diagram has to mark the location and contents of each fixed oil storage container and the storage area for mobile or portable containers. It has to identify exempt underground tanks and label them "exempt." And it has to show all transfer stations and connecting pipes, including intra-facility gathering lines that are otherwise exempt.

That's the legal minimum. In practice, a reviewer walking your site will hold the drawing in one hand and compare it to what's in front of them. Every container that isn't on the page and every pipe run that isn't drawn becomes a question about whether the rest of the Plan can be trusted. In New Jersey, EPA Region 2 enforces the federal SPCC rule, and we cover how inspections work in our guide to who enforces SPCC Plans.

The requirement applies to small facilities too. If you're still sorting out whether you need a Plan at all, start with our four steps to figure out if you need an SPCC Plan. New Jersey adds its own layer for major facilities: DPCC and DCR plans under N.J.A.C. 7:1E carry their own content requirements, so a diagram built for SPCC may need additions if the state plans apply to you. Our guide to SPCC Plans in New Jersey covers how the state and federal pieces fit together.

Screenshot 2025-07-10 141730
NEW JERSEY SPCC PLANS & COMPLIANCE
Visit the New Jersey SPCC Plan Help Center
SPCC requirements, Tier I and Tier II plans, PE certification, costs, five-year reviews, and how RMA helps you develop your plan and stay compliant, all in one place.
Go to the Help Center

What Oil Containers and Equipment Belong on the SPCC Facility Diagram?

Start with an inventory, because the diagram can only be as complete as your list of oil. The Plan has to address the type of oil in each fixed container and its storage capacity. Capacity means what the container can hold, not what's in it the day you walk the site, so a half-full 2,000 gallon tank is recorded as 2,000 gallons. Containers of 55 gallons or more count toward the 1,320 gallon aboveground threshold, as we explain in our piece on whether 55-gallon drums count toward SPCC.

Oil shows up in more forms than fuel tanks. Generator sub-base tanks, hydraulic reservoirs, compressor sumps, transformers, and vegetable oil tanks all count. The table shows what each type needs on the diagram.

Container type What to show on the diagram
Aboveground bulk tanks (diesel, heating oil, used oil) Location, a container ID, the type of oil, and the shell capacity. Mark any dike or containment around them.
Generator sub-base and day tanks Location, ID, oil type, and capacity, drawn as their own containers.
Oil-filled equipment (transformers, hydraulic units) Location, oil type, capacity, and any pad, curb, or other containment.
Drums, totes, and portable containers The boundary of each storage area, plus either the oil type and capacity of each container or an estimate of how many there could be, what they hold, and their sizes.
Underground tanks Location. Mark the tank "exempt" if it's exempt from the rule. A buried tank that isn't exempt gets the same labeling as an aboveground tank.

Whether an underground tank is exempt depends on how it's regulated under the federal UST rules or New Jersey's UST program under N.J.A.C. 7:14B, so confirm that before you write "exempt" on the drawing. Give every container an ID that matches the container table in the Plan, so the reviewer never has to guess which tank you mean.

How Do You Show Transfer Areas and Piping on an SPCC Diagram?

Transfer stations are anywhere oil moves from one place to another: a tank truck delivering diesel, a fueling station, a loading area, or a connection where a hose goes on. The diagram has to include each of them, and it should show where a delivery truck would park, because that tells a reviewer where a hose failure or an overfilled tank would send oil.

The rule also calls for connecting pipes. Draw every run between tanks, fill ports, pumps, and equipment, and mark whether each one is aboveground or buried. Buried piping gets missed most often because nobody can see it, so old as-built drawings and a conversation with whoever maintains the tanks help. Intra-facility gathering lines belong on the drawing too, even where they're exempt from the rest of the rule.

The diagram also supports 40 CFR 112.7(b), which asks the Plan to predict the direction, rate of flow, and total quantity of oil from each type of major equipment failure where experience points to a reasonable chance of one. Flow arrows make that prediction visible.

Screenshot 2025-07-10 141730
NEW JERSEY SPCC PLANS & COMPLIANCE
Visit the New Jersey SPCC Plan Help Center
SPCC requirements, Tier I and Tier II plans, PE certification, costs, five-year reviews, and how RMA helps you develop your plan and stay compliant, all in one place.
Go to the Help Center

How Should Secondary Containment, Drainage, and Nearby Waters Appear on the Diagram?

The rule's diagram sentence doesn't list secondary containment, but the Plan has to address discharge and drainage controls such as secondary containment, and a reviewer expects to find them on the drawing. Outline every dike, berm, curb, drip pan, sump, and containment pallet, and note the containment's size or point to the calculation in the Plan. Our article on how big your SPCC containment needs to be walks through sizing.

Drainage is where a good diagram earns its keep. Mark every storm drain inlet, catch basin, floor drain, separator, ditch, and culvert near your oil, then follow the water. A storm drain next to a fueling area might lead to a municipal storm sewer, or straight to a stream behind the property. Show the outfall, name the receiving water if it has a name, and draw arrows for the direction surface water flows across the site.

nj_spcc_facility_diagram_blog

Example SPCC Facility Diagram for a New Jersey Site

Here's what these pieces look like together on a simple fictional site. This facility has a main building with drum storage inside, a diked pair of aboveground tanks, a generator, a pad-mounted transformer, a truck unloading area, two storm drains, and a stream along the east property line.
